LINK-PP LPJ0026CNL 100% Cross RB1-105B8A1F UDE

Name: LINK-PP LPJ0026CNL 100% Cross RB1-105B8A1F UDE
Brand: Looksaving
SKU: 121121
Price: 0.5 USD
Availability: InStock

Sku. 121121

Organic Search : You Can Get $10 Off For This Products IF $50, Code：ManJian12

$ 0.5

Compatible*

UDE

Competitor P/N*

RB1-105B8A1F

Shipping:: $ 11.49

Can't deliver

To Be Negotiated

to United States Change

Estimated delivery time : 0-27 working days. See details

Total Price:: $ 0.5 $ 0.00 (Save and Extra $0.00 )

Shipping calculated at checkout.

Buy Now

Add to Cart

Add to Inquiry List

/ piece

This item is collected in wish list

Choose your location Shipping Inquiry

Ship to:

United States

Delivery Options and delivery speeds may vary for different locations.

You’ll see exact shipping costs and arrival dates when you checkout.

LINK-PP LPJ0026CNL 100% Cross RB1-105B8A1F UDE

Requirement Details

Your message must be between 20-3,000 characters!

Check your email

Phone

Check your phone number

Submit Requirement

LINK-PP Part Number:	LPJ0026CNL	UDE Part Number	RB1-105B8A1F
Part Status	Active	Connector Type	Jack
Number of Positions/Contacts	8p8c (RJ45, Ethernet)	Application-Lan	Ethernet(NoN PoE)
Number of Ports	1x1 Port	Speed	10/100 Base-T
Latch	Down	Cores per Port	4
Orientation	90° Angle (Right)	PCB Mount Angle	SIDE ENTRY
Shield EMI Tabs	With	LED Option	Without
PCB	FR4	PCB Retaining Post	T POST
Package Height (Inches/mm)	0.528/13.40	Package Length (Inches/mm)	0.839/21.30
Package Width (Inches/mm)	0.626/15.90	Temperature	0 TO 70℃
Bst Circuit	YES	AutomDX	YES
Diodes	No	Contact Mating Area Plating	GOLD 6u"/15u"/30u"
Turns Ratio RX/TX	1CT:1CT	Configuration RX/TX	T,C
